100 Series

Technical Bulletins


Our 100 Series of technical bulletins will give you specific information about EPC encoders, as well as guidance in specifying the right encoders and accessories for your applications.

TB-100

When to Choose the CE Mark

The CE (Conformite European) mark indicates that a product complies with any or all of the European Union (EU) directives, and will affect you only if your system is to be sold in Europe.

Read TB-100

CE-mark_500x333

TB-101

EPC Part Number Description

EPC is often asked, “Why are your part numbers so long?” The answer is that EPC’s encoders are highly-configurable sensing devices with many features and options.

Read TB-101

epc-part-number_755a-shaft_500x333

TB-102

Index Gating Options

Encoder Products Company (EPC) offers several index pulse gating options on most encoder models. The index pulse is also referred to as the reference, marker pulse, or home pulse.

Read TB-102

index-gating-options-cropped_550x366

TB-106

Sealing Options for EPC Encoders

Encoder Products Company uses the international standard IP Code, International Protection Marking, IEC standard 60529, for specifying the sealing qualities of our units.

Read TB-106

IP-ratings-seal-test-img_550x367

TB-107

Effect of Mechanical Jitter

In an encoder, mechanical jitter is any vibration in the assembly affecting the relationship between signal producing components (i.e., disk, sensor, and light source).

Read TB-107

converting_slit-recoil-crop_550x366

TB-108

Encoders with Measuring Wheels

A common method for creating a linear measuring solution is to use a rotary encoder in conjunction with a measuring wheel. Learn how to find the right wheel for your linear measurement application.

Read TB-108

encoders-with-measuring-wheels-tr1-tr3_550x366

TB-109

Specifying Output Types

Choosing the correct number of channels and the correct output type for an encoder can be the determining factor in whether or not a feedback system functions properly.

Read TB-109

pullup-resistor-diagram-cropped_550x366



TB-110

Converting Between Single-Ended & Differential Outputs

The RX/TX and the RX/TXD allow an existing encoder with a single-ended output (Open Collector, Pull-up, or Push-Pull) to be used in applications where the differential signal type is required.

Read TB-110

tech-bulletin-100s_encoder-to-plc-signal-graphic_500x334

TB-111

M12 (12 mm) Connector Options

The economical M12 style connector offers a smaller profile than some other connectors , and offers sealing up to IP69K.

Read TB-111

m12-connectors-on-encoders_top-down-view_500x334

TB-118

A Comparison of Size 25 Encoders

Size 25 shaft encoders and their 58 mm European equivalents are among the most popular encoders in the world. This Tech Bulletin identifies and compares features of EPC's Size 25 models.

Read TB-118

size-25-encoders-examples_550x367

TB-121

Guidelines for Bore & Shaft Tolerances

Maintaining industry acceptable dimensions on shafts and bores is necessary to ensure the proper fit between encoders and the machinery they are installed on.

Read TB-121

shaft-tolerance-closeup_500x367
