M12 Cordsets


M12 Cordset Features

Your EPC encoder is designed to produce a clean, stable and reliable signal in a variety of operating conditions. To ensure that your encoder signal reaches its intended destination (a counter, PLC, or controller, etc.), use Accu-Coder™ mating cordsets.  Our shielded cable and mating connectors have been tested to meet stringent standards for quality and performance. All cable assemblies are assembled in our in-house cable department in accordance with industry best practices. Available in 3-, 4-, 5- and 8-conductor cordset specifications.

stock-075211_M12-5-pin-cordset_crop

5-pin M12 cordset



8-Conductor Cordset Specifications

For use with 8-pin M12 connectors. Always use a shielded cordset.

Stock # Coding Length Shield connected to coupling nut (CE compatible) Available online
075100 A 0.5 m (1.64 ft) No Shop online
075101 A 2 m (6.56 ft) No Shop online
075102 A 4 m (13.12 ft) No Shop online
075103 A 6 m (19.69 ft) No Shop online
075104 A 10 m (32.81 ft) No Shop online
075200 A 2 m (6.56 ft) Yes Shop online
075201 A 4 m (13.12 ft) Yes Shop online
075202 A 6 m (19.69 ft) Yes Shop online
075203 A 10 m (32.81 ft) Yes Shop online

3, 4, 5-Conductor Cordset Specifications

For use with 5-pin M12 connectors. Always use a shielded cordset.

Stock # Coding Description Shield connected to coupling nut (CE compatible) Available online
075205

A

3-Conductor

1 m (3.28 ft)

No n/a
075206

A

4-conductor

1 m (3.28 ft)

No n/a
075204

A

5-conductor

1 m (3.28 ft)

No Shop online
075211

A

5-conductor

1 m (3.28 ft)

Yes Shop online

arrow-alt-circle-right-regularCustomer Service


Questions? Give us a call at (800) 366-5412 or submit this form, and we'll contact you within one business day.

Standard lead time is 4 - 6 days on most models. Expedite options are available on many models. Contact us for details.
