High Resolution 58 mm Thru Bore Encoder | Incremental Rotary Encoders

Model 58T/HF Features

58 mm package available in thru-bore or blind hollow bore
Resolutions from 1 to 65,536 CPR
6 different output types to choose from
32 different waveforms available
Standard and metric bore sizes up to 5/8” and 15 mm
Several flexible mounting options available
IP67 sealing available

download_blue Download Model 58TF/HF datasheet

Purchase Options

Buy through a distributor

Model 58TF Three Point Flex (SE)

3 x 120° 2.25" to 2.75" bolt circle

Model 58TF Block and Pin Flex Mount (SH)

1.36" to 1.71" radius mounting

Model 58TF Tether Arm (SG)

1.75" to 2.95" radius mounting

Model 58TF Tether Arm (SJ)

1.75" to 4.05" radius mounting

Model 58T/HF Description

The Model 58TF 58 mm Accu-CoderPro® thru-bore encoder offers the performance advantages of the programmable Model 58TP, but in an economical, fixed resolution version. Specifically designed for the challenges of an industrial environment, its advanced set of electronics allow the encoder to be factory-programmed to meet your exact application needs. The versatile Model 58TF offers 6 output types, 32 different waveforms, and any resolution from 1 to 65,536 CPR (that’s 262,144 counts in full quadrature). This allows a single encoder to be configured for multiple applications. This encoder is also highly mechanically configurable, offering thru-bore or blind hollow bore options, standard and metric bore sizes up to 5/8” and 15 mm, multiple flex mount options, and a variety of connector types. This flexibility allows one encoder to replace many different part numbers, providing significant cost savings on inventory and downtime replacement costs.
