LP1 Accu-LaserPro™

  • High accuracy programmable non-contact slip free optical encoder

talk to an encoder expert in undera minuteSpeak to a Live Expert in Under 1 Minute

icon_custom engineering_150x150-1-1Custom Engineered Solutions

icon_fast shipping and short lead times_150x150-1-1Fast Shipping & Lead Times




LP1 Accu-LaserPro Features

check-3  Adjustable encoder output A/B up to 120 pulses/mm

check-3   Reverse lock A/B channel for products temporary backward motion

check-3   Input correction factor for adjusting exact distances

check-3   Two freely programmable trigger outputs push/pull, NPN and PNP output with reversible signal level

check-3   Trigger and sequential trigger up to 6.5 m distance

check-3   Trigger block for freely adjustable distance

check-3  Standstill threshold (start/stop threshold) to filter out, for example, startup/shutdown ramps when starting up products (foils, etc.) and micro-vibrations in the movement pattern of products

check-3  Output for signal reversal on change of direction (traversing axes)

check-3  Two mutually monitoring sensors (failure, contamination)

DOWNLOADABLE SOFTWARE

Watch how the LP1 changes the game.

pack expo landing page 2025 - LP1



LP1 Accu-LaserPro

The LP1 Accu-LaserPro is a high accuracy programmable non-contact slip-free optical speed encoder. The laser-based system achieves a higher measuring accuracy and does not damage the material through mechanical wear unlike measuring wheels or other mechanical processes. The LP1 is also able to take over a trigger function and provide a start pulse, for example, as an output for marking devices as soon as the defined increment value has been reached.

LP1_Master_350x350_web



Configure Model

Configure a 3D model of this encoder with the exact specifications for your application. Then download the files in almost any native format, and design it in to your application.

Configure 3D Model

Model LP1

Configure Model

×
  • Buy through a distributor

    Get a Quote

LP1_order guide
